Allen-Bradley 1606-XLB240E | 240W Buffer Module for Short-Term DC Power Backup in Industrial Systems

Overview

The Allen-Bradley 1606-XLB240E is a compact buffer module designed to maintain 24–28V DC output during brief power interruptions. Delivering up to 240W, it bridges short outages without using batteries by storing energy internally through electrolytic capacitors. This module is ideal for preventing equipment resets, data loss, or system shutdowns in industrial control environments.

Key Features

  • Buffered Output Power: Up to 240W

  • Input Voltage Range: 90–264V AC

  • Output Voltage: 24–28V DC

  • Buffer Time: Several seconds depending on load (up to 4 seconds at 10A)

  • No Battery Required: Maintenance-free electrolytic capacitor technology

  • Mounting: DIN rail for easy integration

  • Status Indicators: LEDs for buffer readiness and output status

  • Parallel Operation: Compatible with other 1606 power supplies

Technical Specifications

  • Catalog Number: 1606-XLB240E

  • Series: XLB

  • Input Voltage: 90–264V AC

  • Output Voltage: 24–28V DC

  • Output Power: 240W

  • Output Current: Up to 10A

  • Buffer Time: Up to 4 seconds @ full load

  • Efficiency: ≥98%

  • Protection Class: IP20

  • Mounting Method: DIN rail (EN 60715)

  • Operating Temp: -25°C to +70°C

  • Certifications: UL, CE, cULus, RoHS

Applications

  • Power loss protection in control cabinets

  • PLC and HMI backup

  • Short-term power support for safety systems

  • Industrial automation and machine control

  • Critical monitoring systems

Why Choose the 1606-XLB240E?

  • No Maintenance Required: Capacitor-based buffering eliminates battery upkeep

  • Instant Response: Seamless backup during voltage dips or outages

  • Compact DIN Design: Saves space in control panels

  • Energy Efficient: Minimal heat dissipation, high operational efficiency

  • Industrial-Grade: Designed for demanding environments

Order Now

The Allen-Bradley 1606-XLB240E is in stock and available for immediate worldwide shipping.
