ABB ACS880-01-072A-3 | High-Performance Drive for Flexible and Energy-Efficient Motor Control

Overview

The ABB ACS880-01-072A-3 is a wall-mounted variable frequency drive (VFD) engineered for demanding industrial applications requiring precision and adaptability. Rated at 37 kW and 400 V, this IP21-enclosed drive supports three-phase power and provides superior control for a wide range of motor types using ABB’s Direct Torque Control (DTC) technology.

Key Features

  • Power Rating: 37 kW (50 HP)

  • Input Voltage: 400 V AC ±10%, 3-phase

  • Enclosure Rating: IP21 (for indoor use)

  • Mounting: Wall-mounted design

  • Control Type: Direct Torque Control (DTC) for accurate speed/torque regulation

  • Integrated Features: EMC filter, brake chopper, and control panel

  • User Interface: Assistant control panel with USB support

  • Energy Efficiency: Regenerative braking and energy optimizer

Technical Specifications

  • Catalog Number: ACS880-01-072A-3

  • Rated Current: 72 A

  • Frequency Range: 0 to 500 Hz

  • Ambient Operating Temperature: -15°C to +50°C

  • Cooling Method: Air-cooled with internal fans

  • Communication Options: Modbus, Profibus, EtherCAT (via optional modules)

  • Certifications: CE, UL, cUL, EAC, RoHS compliant

Applications

  • Pumps and fans in HVAC systems

  • Conveyors and material handling systems

  • Extruders, mixers, and compressors

  • Water and wastewater treatment facilities

  • Marine, oil & gas, and mining operations

Why Choose the ABB ACS880-01-072A-3?

  • Precision Motor Control: Accurate regulation with DTC

  • Scalable Integration: Supports a range of fieldbus protocols

  • Space-Saving Design: Wall-mounted with compact footprint

  • Robust and Reliable: Engineered for harsh industrial settings

  • Energy Saving: Built-in tools to optimize energy consumption

Order Now

Available for global delivery.
