Allen-Bradley 1756-L84ES | High-Performance Safety Controller for Demanding Applications

Overview

The Allen-Bradley 1756-L84ES is a GuardLogix 5580 safety controller designed for high-performance and safety-critical applications. It offers 20MB of standard memory and 6MB of safety memory, supporting up to 250 EtherNet/IP nodes. With integrated 1Gbps Ethernet and USB ports, it provides fast communication and easy programming.

Key Features

  • Memory:

    • 20MB standard user memory

    • 6MB safety memory

  • Communication:

    • Embedded 1Gbps EtherNet/IP port

    • USB 2.0 port for programming

  • I/O Capacity:

    • Up to 128,000 digital I/O points

    • Up to 4,000 analog I/O points

  • Tasks and Programs:

    • Supports up to 31 standard tasks and 1 safety task

    • Up to 1,000 programs per task

  • Programming Languages:

    • Relay Ladder Logic (RLL)

    • Structured Text (ST)

    • Function Block Diagram (FBD)

    • Sequential Function Chart (SFC)

  • Safety Compliance:

    • SIL 3, PLe certified

  • Mounting:

    • Chassis-based installation

  • Enclosure:

    • Open-style (IP20)

  • Operating Temperature:

    • 0°C to 60°C (32°F to 140°F)

  • Certifications:

    • UL, cULus, CE, RoHS, ATEX, IECEx, UKCA

Technical Specifications

  • Catalog Number: 1756-L84ES

  • EtherNet/IP Nodes Supported: Up to 250

  • Current Draw:

    • 5 mA @ 1.2V DC

    • 1.2 A @ 5.1V DC

  • Dimensions (HxWxD):

    • 17.78 cm x 5.08 cm x 23.368 cm

  • Weight:

    • Approximately 0.567 kg

Applications

  • Automotive assembly lines

  • Packaging and material handling systems

  • Food and beverage processing

  • Pharmaceutical manufacturing

  • Oil and gas control systems

Why Choose the 1756-L84ES?

  • Integrated Safety: Combines standard and safety control in one controller

  • High Performance: Fast processing and large memory for complex applications

  • Scalability: Supports a wide range of I/O and network configurations

  • Ease of Use: Compatible with Studio 5000 software for programming and configuration

  • Robust Communication: High-speed Ethernet and USB ports for efficient data transfer

Order Now

Available and ready to ship globally.

New & Genuine Products – Factory Sealed At PLCpartssolution, all our products are 100% new, genuine, and come in original factory-sealed packaging. We guarantee authentic components that meet the highest industry standards for performance and reliability.
1-Year Warranty Included All new products sold by PLCpartssolution come with a 1-year warranty. We stand behind the quality and reliability of our parts, ensuring coverage against manufacturing defects under normal operating conditions.
Disclaimer: PLCpartssolution is an independent supplier of surplus and refurbished industrial automation products. We are not an authorized distributor, reseller, or representative of the brands listed on this website. All trademarks, brand names, and logos are the property of their respective owners. PLCpartssolution is not affiliated with, endorsed by, or approved by ABB, Fanuc, B&R, Rockwell Automation, Schneider Electric, Siemens, or any other manufacturers mentioned.
