Allen-Bradley 2094-BC01-M01-S shunt module, 460V, 1-axis, integrated resistor, Kinetix 6000.

Allen-Bradley 2094-BC01-M01-S

SKU: 2094-BC01-M01-S
Your Price:
$6,930.00
Add to wishlist
Checkout Secure
Order in the next to get it by

10+ Available in Stock

  • Image of Free Shipping on All Orders

    Free Shipping on All Orders
  • Image of 1 Year Warranty

    We will beat any price

    1 Year Warranty
  • Image of Experts Aavaiable 7/24/365

    Free shipping

    Experts Aavaiable 7/24/365
  • Image of 30 days money-back

    30 days money-back

Allen-Bradley 2094-BC01-M01-S

Product Overview

The Allen-Bradley 2094-BC01-M01-S is a Bulletin 2094 shunt module designed for use with Kinetix 6000 servo drive systems. Rated for 460V AC operation, this single-axis module features a built-in shunt resistor and helps manage regenerative braking energy produced by servo motors. Ideal for high-inertia or decelerating loads, the unit ensures safe dissipation of excess energy and protects connected equipment.

Key Highlights

  • Voltage Rating: 460V AC, 3-phase

  • Configuration: Single-axis brake/shunt module

  • Integrated Resistor: Yes — built-in braking resistor

  • Function: Dissipates regenerated energy during motor deceleration

  • Series: B

  • Enclosure Type: Open (panel mount)

  • Compatible System: Kinetix 6000 multi-axis servo drives

  • Built-in overload and thermal protection

Detailed Specifications

  • Part Number: 2094-BC01-M01-S

  • Line Voltage: 342–528V AC

  • Axis: 1-axis brake control

  • Continuous Shunt Power: Approx. 100W (verify by full spec)

  • Peak Shunt Energy: Application dependent

  • Cooling: Natural convection

  • Dimensions (H x W x D): Approx. 200 mm x 50 mm x 150 mm

  • Mounting: Panel-mount vertical orientation

  • Certifications: UL, CE, RoHS, cUL

  • Operating Temp: 0°C to 50°C (no derating)

Common Uses

  • Servo applications with regenerative braking

  • Packaging and conveyor systems

  • CNC and machine tools

  • High-inertia load handling

  • Safety systems in servo drive networks

Why It Stands Out

  • Prevents overvoltage from motor regeneration

  • Compact module integrates directly with Kinetix 6000

  • Reduces the need for external brake resistors

  • Enhances reliability and protection in drive systems

  • Part of the trusted Allen-Bradley motion portfolio

Get Yours Today

The Allen-Bradley 2094-BC01-M01-S shunt module is in stock and available now.

New & Genuine Products – Factory Sealed At PLCpartssolution, all our products are 100% new, genuine, and come in original factory-sealed packaging. We guarantee authentic components that meet the highest industry standards for performance and reliability.
1-Year Warranty Included All new products sold by PLCpartssolution come with a 1-year warranty. We stand behind the quality and reliability of our parts, ensuring coverage against manufacturing defects under normal operating conditions.
Disclaimer: PLCpartssolution is an independent supplier of surplus and refurbished industrial automation products. We are not an authorized distributor, reseller, or representative of the brands listed on this website. All trademarks, brand names, and logos are the property of their respective owners. PLCpartssolution is not affiliated with, endorsed by, or approved by ABB, Fanuc, B&R, Rockwell Automation, Schneider Electric, Siemens, or any other manufacturers mentioned.
