Allen-Bradley 2094-BC02-M02 Kinetix 6000 shunt module, 460V AC, dual channel, internal brake resistor.

Allen-Bradley 2094-BC02-M02

SKU: 2094-BC02-M02
Your Price:
$7,576.00
Add to wishlist
Checkout Secure
Order in the next to get it by

10+ Available in Stock

  • Image of Free Shipping on All Orders

    Free Shipping on All Orders
  • Image of 1 Year Warranty

    We will beat any price

    1 Year Warranty
  • Image of Experts Aavaiable 7/24/365

    Free shipping

    Experts Aavaiable 7/24/365
  • Image of 30 days money-back

    30 days money-back

Allen-Bradley 2094-BC02-M02

Overview

The Allen-Bradley 2094-BC02-M02 is a shunt module designed for use in Kinetix 6000 common bus servo drive systems. It manages excess regenerative energy during deceleration, ensuring stable voltage levels across the DC bus. The module supports two independent channels and includes an internal brake resistor, making it an effective solution for high-inertia and dynamic motion control applications.

Key Features

  • Series: Kinetix 6000

  • Function: Common bus energy shunt module

  • Voltage: 400–480V AC, 3-phase

  • Channels: 2 (independent)

  • Brake Resistor: Integrated

  • Mounting: Panel mount (vertical orientation)

  • LED Indicators: Status and fault diagnostics

  • Helps prevent overvoltage shutdowns during braking

  • Designed for coordinated multi-axis systems

Technical Specifications

  • Catalog Number: 2094-BC02-M02

  • Input Voltage Range: 400–480V AC

  • Continuous Power Dissipation: ~150W per channel

  • Operating Temperature: 0 to 50 °C (32 to 122 °F)

  • Enclosure: IP20 open type

  • Cooling Method: Natural convection

  • Dimensions: Approx. 360 x 200 x 170 mm

  • Certifications: UL, CE, cULus

Applications

  • Multi-axis coordinated motion

  • High-inertia load control

  • Packaging and converting machines

  • Robotics and automated material handling

  • Servo drive systems using regenerative braking

Why Choose the 2094-BC02-M02?

  • Manages regenerative energy to protect your drive system

  • Integrated brake resistor simplifies system design

  • Compact solution for common bus installations

  • Dual-channel design allows for flexible configurations

  • Designed for performance in motion-intensive environments

Order Now

The Allen-Bradley 2094-BC02-M02 shunt module is available and ready to ship.

New & Genuine Products – Factory Sealed At PLCpartssolution, all our products are 100% new, genuine, and come in original factory-sealed packaging. We guarantee authentic components that meet the highest industry standards for performance and reliability.
1-Year Warranty Included All new products sold by PLCpartssolution come with a 1-year warranty. We stand behind the quality and reliability of our parts, ensuring coverage against manufacturing defects under normal operating conditions.
Disclaimer: PLCpartssolution is an independent supplier of surplus and refurbished industrial automation products. We are not an authorized distributor, reseller, or representative of the brands listed on this website. All trademarks, brand names, and logos are the property of their respective owners. PLCpartssolution is not affiliated with, endorsed by, or approved by ABB, Fanuc, B&R, Rockwell Automation, Schneider Electric, Siemens, or any other manufacturers mentioned.
