Allen-Bradley 1794-IB16D FLEX I/O 16-channel 24V DC sinking input module with diagnostics

Allen-Bradley 1794-IB16D

SKU: 1794-IB16D
Your Price:
$350.00
Add to wishlist
Checkout Secure
Order in the next to get it by

10+ Available in Stock

  • Image of Free Shipping on All Orders

    Free Shipping on All Orders
  • Image of 1 Year Warranty

    We will beat any price

    1 Year Warranty
  • Image of Experts Aavaiable 7/24/365

    Free shipping

    Experts Aavaiable 7/24/365
  • Image of 30 days money-back

    30 days money-back

Allen-Bradley 1794-IB16D

Overview

The Allen-Bradley 1794-IB16D is a 16-channel digital input module with diagnostic capability, part of the FLEX I/O family. It supports 24V DC sinking inputs and integrates easily into distributed control architectures. Designed for applications requiring input status and fault detection, the module provides advanced diagnostics in a compact, modular form factor.

Key Features

  • Number of Inputs: 16

  • Input Type: Digital, sinking (negative logic)

  • Input Voltage: 24V DC nominal (10–31.2V DC range)

  • Diagnostics: Open circuit, short circuit, and status indication

  • Mounting: Compatible with FLEX I/O terminal bases

  • Status Indicators: LED indicators per channel

  • Backplane Communication: Via FLEX adapter modules

Technical Specifications

  • Catalog Number: 1794-IB16D

  • Input Current: 3.0 mA per channel

  • Input Delay (On/Off): 0.5 ms typical

  • Power Dissipation: 4.0 W max

  • Thermal Dissipation: 13.6 BTU/hr

  • Operating Temperature: 0°C to +55°C

  • Storage Temperature: -40°C to +85°C

  • Certifications: UL, CE, CSA, C-Tick

  • Isolation Voltage: 50V (continuous), tested at 850V AC for 60 s

Applications

  • Distributed I/O systems

  • Industrial automation and control

  • Machine safety and diagnostics

  • Material handling systems

  • Factory monitoring and logic control

Why Choose the 1794-IB16D

  • Advanced Diagnostics: Detects open/short circuit and input faults

  • High-Density Input: 16 channels in a compact module

  • Modular Integration: Flexible mounting and configuration

  • FLEX I/O Compatible: Seamlessly fits into existing setups

  • Global Approvals: UL, CE, and CSA certified for international use

Order Now

The Allen-Bradley 1794-IB16D input module is in stock and ships worldwide.

New & Genuine Products – Factory Sealed At PLCpartssolution, all our products are 100% new, genuine, and come in original factory-sealed packaging. We guarantee authentic components that meet the highest industry standards for performance and reliability.
1-Year Warranty Included All new products sold by PLCpartssolution come with a 1-year warranty. We stand behind the quality and reliability of our parts, ensuring coverage against manufacturing defects under normal operating conditions.
Disclaimer: PLCpartssolution is an independent supplier of surplus and refurbished industrial automation products. We are not an authorized distributor, reseller, or representative of the brands listed on this website. All trademarks, brand names, and logos are the property of their respective owners. PLCpartssolution is not affiliated with, endorsed by, or approved by ABB, Fanuc, B&R, Rockwell Automation, Schneider Electric, Siemens, or any other manufacturers mentioned.
