Allen-Bradley 193-T1AC16 overload relay, 1.0–1.6A, Class 10, manual/auto reset, DIN rail mount, for 100-C contactors

Allen-Bradley 193-T1AC16

SKU: 193-T1AC16
Your Price:
$236.00
Add to wishlist
Checkout Secure
Order in the next to get it by

10+ Available in Stock

  • Image of Free Shipping on All Orders

    Free Shipping on All Orders
  • Image of 1 Year Warranty

    We will beat any price

    1 Year Warranty
  • Image of Experts Aavaiable 7/24/365

    Free shipping

    Experts Aavaiable 7/24/365
  • Image of 30 days money-back

    30 days money-back

Allen-Bradley 193-T1AC16

Overview

The Allen-Bradley 193-T1AC16 is a Class 10 thermal overload relay designed to provide reliable motor protection in coordination with 100-C series contactors. With an adjustable current range of 1.0 to 1.6 amps, this relay offers manual or automatic reset options, trip indication, and easy mounting to standard DIN rails, making it ideal for compact motor control centers.

Key Features

  • Type: Thermal overload relay

  • Current Range: 1.0 – 1.6A (adjustable)

  • Trip Class: Class 10 (fast-acting for motor protection)

  • Reset Method: Manual or automatic

  • Mounting Type: DIN rail or direct on 100-C contactors

  • Trip Indication: Visual indication of overload trip

  • Phase Loss Sensitivity: Built-in

  • Auxiliary Contacts: 1 N.O. + 1 N.C. standard

Technical Specifications

  • Catalog Number: 193-T1AC16

  • Compatible Contactors: 100-C09 to 100-C23

  • Operational Voltage: Up to 690V AC

  • Rated Insulation Voltage: 690V

  • Thermal Trip Class: Class 10

  • Ambient Compensation: -20°C to +60°C

  • Auxiliary Contact Rating: AC-15: 3A @ 240V | DC-13: 1A @ 125V

  • Certifications: UL, CSA, CE, RoHS

Applications

  • Motor overload protection

  • Pump and fan systems

  • HVAC and compressor control

  • Conveyor and machine automation

  • Control panels and starter assemblies

Why Choose the 193-T1AC16

  • Adjustable range ensures precise motor protection

  • Fast-acting trip helps prevent equipment damage

  • Mounts directly to 100-C contactors or DIN rail

  • Dual reset modes for flexible maintenance practices

  • Built-in trip indicator for easy diagnostics

Order Now

The Allen-Bradley 193-T1AC16 overload relay is available and ships worldwide.

New & Genuine Products – Factory Sealed At PLCpartssolution, all our products are 100% new, genuine, and come in original factory-sealed packaging. We guarantee authentic components that meet the highest industry standards for performance and reliability.
1-Year Warranty Included All new products sold by PLCpartssolution come with a 1-year warranty. We stand behind the quality and reliability of our parts, ensuring coverage against manufacturing defects under normal operating conditions.
Disclaimer: PLCpartssolution is an independent supplier of surplus and refurbished industrial automation products. We are not an authorized distributor, reseller, or representative of the brands listed on this website. All trademarks, brand names, and logos are the property of their respective owners. PLCpartssolution is not affiliated with, endorsed by, or approved by ABB, Fanuc, B&R, Rockwell Automation, Schneider Electric, Siemens, or any other manufacturers mentioned.
