Allen-Bradley 22F-D6P0N113

Overview

The Allen-Bradley 22F-D6P0N113 is a compact and cost-effective PowerFlex 4M AC drive designed for general-purpose motor control in industrial applications. This model supports 480V AC three-phase input, delivering 6 amps of current to handle motors up to 3 HP (2.2 kW). Housed in an IP20 open-type enclosure, it features an LED display, a fixed digital keypad, and an internal CE-compliant filter. It is ideal for users needing reliable and space-saving VFDs without dynamic braking.


Key Features

  • Series: PowerFlex 4M

  • Power Rating: 3 HP (2.2 kW)

  • Input Voltage: 480V AC

  • Input Phase: 3-phase

  • Output Current: 6 A

  • Frame Size: B

  • Enclosure Type: IP20 (open)

  • Display: LED with fixed digital keypad

  • Filter: Internal CE-compliant EMC filter

  • Brake: No dynamic braking transistor

  • Motor Control: V/Hz and Sensorless Vector


Technical Specifications

  • Catalog Number: 22F-D6P0N113

  • Input Frequency: 50/60 Hz

  • Output Frequency Range: 0–400 Hz

  • Control Method: Volts per Hertz (V/Hz), Sensorless Vector Control

  • Speed Regulation: ±0.5% (Sensorless Vector)

  • Ambient Operating Temperature: -10°C to +50°C (without derating)

  • Communication Options: RS485 (Modbus RTU)

  • Certifications: UL, CE, cUL, RoHS

  • Dimensions: Approx. 180 x 100 x 150 mm (H x W x D)


Applications

  • Conveyors and packaging lines

  • HVAC fan and pump systems

  • Light industrial machinery

  • Material handling equipment

  • OEM machine control


Why Choose the 22F-D6P0N113

  • Reliable motor control in a compact frame

  • Pre-installed CE filter for EMC compliance

  • Easy-to-use keypad and LED interface

  • Ideal for cost-sensitive applications without braking needs

  • Backed by Rockwell Automation’s global support


Order Now

The Allen-Bradley 22F-D6P0N113 PowerFlex 4M AC drive is available and ships worldwide.

New & Genuine Products – Factory Sealed At PLCpartssolution, all our products are 100% new, genuine, and come in original factory-sealed packaging. We guarantee authentic components that meet the highest industry standards for performance and reliability.
1-Year Warranty Included All new products sold by PLCpartssolution come with a 1-year warranty. We stand behind the quality and reliability of our parts, ensuring coverage against manufacturing defects under normal operating conditions.
Disclaimer: PLCpartssolution is an independent supplier of surplus and refurbished industrial automation products. We are not an authorized distributor, reseller, or representative of the brands listed on this website. All trademarks, brand names, and logos are the property of their respective owners. PLCpartssolution is not affiliated with, endorsed by, or approved by ABB, Fanuc, B&R, Rockwell Automation, Schneider Electric, Siemens, or any other manufacturers mentioned.
