Schneider Electric ATV320U04N4B

SKU: ATV320U04N4B
Your Price:
$460.00
Add to wishlist
Checkout Secure
Order in the next to get it by

10+ Available in Stock

  • Image of Free Shipping on All Orders

    Free Shipping on All Orders
  • Image of 1 Year Warranty

    We will beat any price

    1 Year Warranty
  • Image of Experts Aavaiable 7/24/365

    Free shipping

    Experts Aavaiable 7/24/365
  • Image of 30 days money-back

    30 days money-back

Schneider Electric ATV320U04N4B

Overview

The Schneider Electric ATV320U04N4B is a compact and versatile variable frequency drive (VFD) from the Altivar 320 series, designed to control three-phase asynchronous and synchronous motors up to 4 kW (5 HP). With robust features, advanced motor control functions, and easy integration into automation systems, it is ideal for industrial and commercial applications.


Key Features

  • Series: Altivar 320

  • Power Rating: 4 kW / 5 HP

  • Input Voltage: 3-phase, 380–480 V AC ±10%

  • Output Frequency: 0.1 to 599 Hz

  • Control Methods: V/F, sensorless vector control

  • Overload Capacity: 150% for 60 seconds

  • Enclosure Rating: IP20 (panel mounting)

  • Integrated Communications: Modbus RTU, CANopen

  • Display: Optional remote keypad with LCD

  • Mounting: DIN rail or surface panel mount


Technical Specifications

  • Model Number: ATV320U04N4B

  • Rated Output Current: 9.5 A

  • Max Current (Overload): 14.25 A

  • Switching Frequency: 2 to 16 kHz (adjustable)

  • Ambient Temperature: –10 °C to 50 °C without derating

  • Dimensions (H×W×D): Approx. 190 × 85 × 152 mm

  • Weight: ~1.6 kg

  • Motor Control: Asynchronous and permanent magnet motors

  • Cooling: Integrated fan

  • Certifications: CE, UL, CSA, EAC, RCM


Applications

  • Conveyors and material handling systems

  • HVAC: fans, blowers, and pumps

  • Packaging and bottling machines

  • General-purpose industrial automation

  • OEM machine control systems


Why Choose the ATV320U04N4B

  • Space-Saving Design: Compact IP20 housing for easy panel integration

  • Efficient Motor Control: Supports precise torque and speed adjustment

  • Flexible Communication: Ready for Modbus and CANopen networks

  • Robust Performance: Reliable under harsh industrial conditions

  • Easy Setup: User-friendly configuration and remote keypad option


Order Now

The Schneider Electric ATV320U04N4B is a high-performance and compact VFD, perfect for motor control in industrial environments. Available for global shipping.



New & Genuine Products – Factory Sealed At PLCpartssolution, all our products are 100% new, genuine, and come in original factory-sealed packaging. We guarantee authentic components that meet the highest industry standards for performance and reliability.
1-Year Warranty Included All new products sold by PLCpartssolution come with a 1-year warranty. We stand behind the quality and reliability of our parts, ensuring coverage against manufacturing defects under normal operating conditions.
Disclaimer: PLCpartssolution is an independent supplier of surplus and refurbished industrial automation products. We are not an authorized distributor, reseller, or representative of the brands listed on this website. All trademarks, brand names, and logos are the property of their respective owners. PLCpartssolution is not affiliated with, endorsed by, or approved by ABB, Fanuc, B&R, Rockwell Automation, Schneider Electric, Siemens, or any other manufacturers mentioned.

Description

Schneider Electric ATV320U04N4B

Overview

The Schneider Electric ATV320U04N4B is a compact and versatile variable frequency drive (VFD) from the Altivar 320 series, designed to control three-phase asynchronous and synchronous motors up to 4 kW (5 HP). With robust features, advanced motor control functions, and easy integration into automation systems, it is ideal for industrial and commercial applications.


Key Features

  • Series: Altivar 320

  • Power Rating: 4 kW / 5 HP

  • Input Voltage: 3-phase, 380–480 V AC ±10%

  • Output Frequency: 0.1 to 599 Hz

  • Control Methods: V/F, sensorless vector control

  • Overload Capacity: 150% for 60 seconds

  • Enclosure Rating: IP20 (panel mounting)

  • Integrated Communications: Modbus RTU, CANopen

  • Display: Optional remote keypad with LCD

  • Mounting: DIN rail or surface panel mount


Technical Specifications

  • Model Number: ATV320U04N4B

  • Rated Output Current: 9.5 A

  • Max Current (Overload): 14.25 A

  • Switching Frequency: 2 to 16 kHz (adjustable)

  • Ambient Temperature: –10 °C to 50 °C without derating

  • Dimensions (H×W×D): Approx. 190 × 85 × 152 mm

  • Weight: ~1.6 kg

  • Motor Control: Asynchronous and permanent magnet motors

  • Cooling: Integrated fan

  • Certifications: CE, UL, CSA, EAC, RCM


Applications

  • Conveyors and material handling systems

  • HVAC: fans, blowers, and pumps

  • Packaging and bottling machines

  • General-purpose industrial automation

  • OEM machine control systems


Why Choose the ATV320U04N4B

  • Space-Saving Design: Compact IP20 housing for easy panel integration

  • Efficient Motor Control: Supports precise torque and speed adjustment

  • Flexible Communication: Ready for Modbus and CANopen networks

  • Robust Performance: Reliable under harsh industrial conditions

  • Easy Setup: User-friendly configuration and remote keypad option


Order Now

The Schneider Electric ATV320U04N4B is a high-performance and compact VFD, perfect for motor control in industrial environments. Available for global shipping.



Condition

New & Genuine Products – Factory Sealed At PLCpartssolution, all our products are 100% new, genuine, and come in original factory-sealed packaging. We guarantee authentic components that meet the highest industry standards for performance and reliability.

Warranty

1-Year Warranty Included All new products sold by PLCpartssolution come with a 1-year warranty. We stand behind the quality and reliability of our parts, ensuring coverage against manufacturing defects under normal operating conditions.

Disclaimer

Disclaimer: PLCpartssolution is an independent supplier of surplus and refurbished industrial automation products. We are not an authorized distributor, reseller, or representative of the brands listed on this website. All trademarks, brand names, and logos are the property of their respective owners. PLCpartssolution is not affiliated with, endorsed by, or approved by ABB, Fanuc, B&R, Rockwell Automation, Schneider Electric, Siemens, or any other manufacturers mentioned.
