Schneider Electric ATV320U22N4C 15 kW compact variable speed drive for 380–480 V motors

Schneider Electric ATV320U22N4C

SKU: ATV320U22N4C
Your Price:
$430.00
Add to wishlist
Checkout Secure
Order in the next to get it by

10+ Available in Stock

  • Image of Free Shipping on All Orders

    Free Shipping on All Orders
  • Image of 1 Year Warranty

    We will beat any price

    1 Year Warranty
  • Image of Experts Aavaiable 7/24/365

    Free shipping

    Experts Aavaiable 7/24/365
  • Image of 30 days money-back

    30 days money-back

Schneider Electric ATV320U22N4C

Overview

The ATV320U22N4C is a 22 HP (15 kW) compact variable speed drive from Schneider Electric’s Altivar 320 series, designed for robust industrial motor control. With support for 380–480 V AC, it is ideal for applications such as HVAC, pumps, fans, conveyors, and fluid handling. It features Safe Torque Off (STO) safety, energy-efficient operation, and a compact, panel-mountable form factor.

Key Features

  • Power Rating: 15 kW (22 HP)

  • Voltage Input: 380–480 V AC, 50/60 Hz

  • Output Current: Approximately 30 A

  • Control Modes: V/Hz, sensorless vector, torque control

  • Safety Feature: Integrated Safe Torque Off (STO)

  • Form Factor: IP20 rated enclosure

  • Communication: Embedded Modbus RTU/ASCII

  • Expansion: Optional EtherNet/IP, Profibus, CANopen modules

Technical Specifications

  • Catalog Number: ATV320U22N4C

  • Frequency Range: 0.1 Hz to 400 Hz

  • Switching Frequency: Default 4 kHz; adjustable to 12 kHz

  • Operating Temperature: –10 °C to +50 °C (derates above 40 °C)

  • Storage Temperature: –40 °C to +85 °C

  • Vibration: 3 gn; Shock: 15 gn

  • Cooling Method: Natural convection; forced-air kit available

  • Mounting: Panel or wall mount

  • Dimensions: Approx. 142 × 330 × 183 mm

  • Weight: Approx. 9.5 kg

  • Certifications: CE, UL, CSA, RoHS compliant

Applications

  • HVAC systems including pumps and fans

  • Conveyor systems and material handling

  • OEM machinery automation

  • Water and wastewater treatment drives

  • Efficient motor control in compact industrial panels

Why Choose the ATV320U22N4C

  • High-performance in a compact size

  • Built-in STO enhances safety compliance

  • Flexible communication options with modular cards

  • Energy-efficient drive operation

  • Durable, designed for industrial environments

Order Now

The Schneider Electric ATV320U22N4C compact drive is available for immediate worldwide shipping.



New & Genuine Products – Factory Sealed At PLCpartssolution, all our products are 100% new, genuine, and come in original factory-sealed packaging. We guarantee authentic components that meet the highest industry standards for performance and reliability.
1-Year Warranty Included All new products sold by PLCpartssolution come with a 1-year warranty. We stand behind the quality and reliability of our parts, ensuring coverage against manufacturing defects under normal operating conditions.
Disclaimer: PLCpartssolution is an independent supplier of surplus and refurbished industrial automation products. We are not an authorized distributor, reseller, or representative of the brands listed on this website. All trademarks, brand names, and logos are the property of their respective owners. PLCpartssolution is not affiliated with, endorsed by, or approved by ABB, Fanuc, B&R, Rockwell Automation, Schneider Electric, Siemens, or any other manufacturers mentioned.
