Pepperl+Fuchs NBB15‑U1K‑N0 | Inductive Sensor | 15 mm | Flush | PNP NO/NC | M18 Housing | IP67
Overview
The Pepperl+Fuchs NBB15‑U1K‑N0 is a robust flush-mount inductive proximity sensor with a generous 15 mm sensing range. It features switchable PNP output (NO/NC), rugged M18 threaded housing, IP67 ingress protection, and clear LED status indication—designed for reliable metal detection in industrial automation and machinery environments.
Key Features
-
Sensing Range: 15 mm flush-mount configuration
-
Output Type: PNP with switchable normally open (NO) or normally closed (NC) logic
-
Housing: M18 nickel-plated brass for durability
-
Protection Rating: IP67 against dust and moisture
-
Connection: M12 4-pin connector or factory-wired cable
-
LED Indicator: Yellow LED for clear switching feedback
-
Operating Voltage: 10–30 V DC
-
Electrical Safeguards: Reverse polarity and short-circuit protection included
Technical Specifications
Specification | Details |
---|---|
Part Number | NBB15‑U1K‑N0 |
Manufacturer | Pepperl+Fuchs |
Sensing Distance | 15 mm (flush mount) |
Output Configuration | PNP, switchable NO/NC |
Current Rating | Up to 200 mA |
Voltage Drop | Typically ≤ 2 V |
Supply Voltage | 10–30 V DC |
Switching Frequency | Up to ~300 Hz |
Connection Type | M12 4‑pin connector or cable |
Housing Material | Nickel-plated brass |
Thread Size | M18 × 1 mm |
Protection Rating | IP67 |
Operating Temperature | –25 °C to +70 °C |
Certifications | CE, cULus |
Applications
-
Large metal part detection in conveyor and sorting systems
-
Position sensing in automated machinery
-
Metal presence monitoring in packaging equipment
-
OEM control panels and machine automation
-
Environments with splash, dust, or moisture exposure
Why Choose the NBB15‑U1K‑N0
-
Flush design allows seamless mounting for hygienic applications
-
Switchable PNP output provides logic flexibility
-
Extended range simplifies detection of larger components
-
Rugged M18 housing endures industrial stress
-
LED diagnostics speed up installation and maintenance
-
Built to Pepperl+Fuchs’s high-quality standards
Order Now
The Pepperl+Fuchs NBB15‑U1K‑N0 inductive proximity sensor is in stock and ships worldwide.
Description
Pepperl+Fuchs NBB15‑U1K‑N0 | Inductive Sensor | 15 mm | Flush | PNP NO/NC | M18 Housing | IP67
Overview
The Pepperl+Fuchs NBB15‑U1K‑N0 is a robust flush-mount inductive proximity sensor with a generous 15 mm sensing range. It features switchable PNP output (NO/NC), rugged M18 threaded housing, IP67 ingress protection, and clear LED status indication—designed for reliable metal detection in industrial automation and machinery environments.
Key Features
-
Sensing Range: 15 mm flush-mount configuration
-
Output Type: PNP with switchable normally open (NO) or normally closed (NC) logic
-
Housing: M18 nickel-plated brass for durability
-
Protection Rating: IP67 against dust and moisture
-
Connection: M12 4-pin connector or factory-wired cable
-
LED Indicator: Yellow LED for clear switching feedback
-
Operating Voltage: 10–30 V DC
-
Electrical Safeguards: Reverse polarity and short-circuit protection included
Technical Specifications
Specification | Details |
---|---|
Part Number | NBB15‑U1K‑N0 |
Manufacturer | Pepperl+Fuchs |
Sensing Distance | 15 mm (flush mount) |
Output Configuration | PNP, switchable NO/NC |
Current Rating | Up to 200 mA |
Voltage Drop | Typically ≤ 2 V |
Supply Voltage | 10–30 V DC |
Switching Frequency | Up to ~300 Hz |
Connection Type | M12 4‑pin connector or cable |
Housing Material | Nickel-plated brass |
Thread Size | M18 × 1 mm |
Protection Rating | IP67 |
Operating Temperature | –25 °C to +70 °C |
Certifications | CE, cULus |
Applications
-
Large metal part detection in conveyor and sorting systems
-
Position sensing in automated machinery
-
Metal presence monitoring in packaging equipment
-
OEM control panels and machine automation
-
Environments with splash, dust, or moisture exposure
Why Choose the NBB15‑U1K‑N0
-
Flush design allows seamless mounting for hygienic applications
-
Switchable PNP output provides logic flexibility
-
Extended range simplifies detection of larger components
-
Rugged M18 housing endures industrial stress
-
LED diagnostics speed up installation and maintenance
-
Built to Pepperl+Fuchs’s high-quality standards
Order Now
The Pepperl+Fuchs NBB15‑U1K‑N0 inductive proximity sensor is in stock and ships worldwide.
