Pepperl+Fuchs NBN40‑L2‑A2‑V1 | Inductive Proximity Sensor | 40 mm Sensing | M30 Housing

Overview

The NBN40‑L2‑A2‑V1 is a heavy-duty inductive proximity sensor from Pepperl+Fuchs, offering a 40 mm flush sensing distance in a compact M30 metal housing. Designed for demanding industrial applications, it delivers accurate, non-contact metal detection with robust environmental protection and fast response time.


Key Features

  • Sensing Distance: 40 mm (flush mount)

  • Output Type: PNP, Normally Open (NO)

  • Electrical Design: 3‑wire DC with fast switching

  • Connection: M30 threaded connector

  • Housing: Nickel-plated brass, IP67 rated

  • LED Indicator: Built-in output status light

  • Switching Frequency: Up to 100 Hz


Technical Specifications

Specification Details
Model NBN40‑L2‑A2‑V1
Supply Voltage 10–30 V DC
Sensing Range (Sn) 40 mm (flush)
Switching Frequency ≤ 100 Hz
Output Current Max 200 mA
Voltage Drop ≤ 2 V
Operating Temp. –25 °C to +70 °C
Protection Class IP67
Housing Length ~75 mm
Mounting Style Flush
Connection Type M30 connector, 4‑pin
Standards Compliance EN 60947‑5‑2

Applications

  • Position sensing in heavy-duty conveyor systems

  • Detection of metal components in industrial assembly

  • Automation in machine tools and robotic cells

  • OEM systems requiring extended 40 mm sensing

  • Harsh environments where robust sensors are essential


Why Choose NBN40‑L2‑A2‑V1

  • Long Detection Range: Efficient 40 mm flush detection

  • Rugged Reliability: Durable M30 metal housing with IP67 rating

  • Accurate & Fast: PNP NO output with quick switching

  • Visual Feedback: Integrated LED for fast status checks

  • Industrial Compatibility: Fully compliant with PLC systems


Order Now

The Pepperl+Fuchs NBN40‑L2‑A2‑V1 inductive proximity sensor is in stock and ships worldwide.

New & Genuine Products – Factory Sealed At PLCpartssolution, all our products are 100% new, genuine, and come in original factory-sealed packaging. We guarantee authentic components that meet the highest industry standards for performance and reliability.
1-Year Warranty Included All new products sold by PLCpartssolution come with a 1-year warranty. We stand behind the quality and reliability of our parts, ensuring coverage against manufacturing defects under normal operating conditions.
