Pepperl+Fuchs NJ15‑U1‑E2 | Inductive Proximity Sensor | 15 mm | Non‑Flush | PNP NO | M18 Housing | IP67
Overview
The Pepperl+Fuchs NJ15‑U1‑E2 is a non‑flush inductive proximity sensor boasting a 15 mm sensing distance and PNP normally open output. Housed in a robust M18 nickel‑plated brass body with IP67 protection, this sensor offers reliable metal detection in harsh industrial settings, including damp, dusty, and high-vibration environments.
Key Features
-
Sensing Distance: 15 mm non‑flush mounting
-
Output Type: PNP normally open (NO)
-
Housing: M18 × 1 nickel-plated brass
-
Connection: Cable or M12 connector options
-
Protection: IP67 for dust and water ingress
-
Supply Voltage: 10–30 V DC
-
Switching Frequency: Up to approx. 200 Hz
-
Indicator: Yellow LED for switching status
-
Safety Features: Short-circuit and reverse-polarity protection
Technical Specifications
Specification | Details |
---|---|
Part Number | NJ15‑U1‑E2 |
Manufacturer | Pepperl+Fuchs |
Sensing Range | 15 mm non‑flush |
Output Configuration | PNP, normally open |
Current Rating | ≤ 200 mA |
Voltage Drop | ≤ 2 V |
Voltage Supply | 10–30 V DC |
Switching Frequency | ≤ ~200 Hz |
Connection Type | M12 connector or cable |
Housing Material | Nickel-plated brass |
Thread Size | M18 × 1 mm |
Protection Rating | IP67 |
Operating Temperature | –25 °C to +70 °C |
Certifications | CE, cULus |
Applications
-
Metal detection on conveyor systems
-
Position sensing in industrial automation
-
Robotics and OEM machinery feedback
-
Presence detection in packaging lines
-
Harsh-environment installations requiring sealed sensors
Why Choose the NJ15‑U1‑E2
-
Reliable 15 mm detection in a compact, rugged form
-
Durable metal housing withstands rough industrial conditions
-
PNP output easily interfaces with modern control systems
-
Fast switching supports dynamic automation needs
-
LED status feedback simplifies setup and troubleshooting
-
Built to last, with protection from short circuits and polarity errors
Order Now
The Pepperl+Fuchs NJ15‑U1‑E2 inductive proximity sensor is in stock and ships worldwide.
