Pepperl+Fuchs VAA‑4E4A‑KE‑ZE/R | AS-Interface Module | 4 Inputs + 4 Outputs | IP67 | Flat Cable Connection
Overview
The Pepperl+Fuchs VAA‑4E4A‑KE‑ZE/R is a rugged AS‑Interface (AS‑i) module designed for decentralized automation applications. It features 4 digital inputs and 4 digital outputs, each with M12 connectors, and supports flat cable connection with insulation-piercing technology. The module is encased in a compact IP67-rated housing for reliable operation in harsh industrial environments.
Key Features
-
AS‑Interface I/O module with 4 inputs and 4 outputs
-
M12 connection ports for field devices
-
Flat cable piercing connection for AS-i power and data
-
Outputs protected against overload and short-circuit
-
Integrated addressing socket
-
LED indicators for power, communication, input, and output states
-
IP67 protection rating for outdoor or washdown applications
-
Mounts directly to machine or structure
Technical Specifications
Specification | Value |
---|---|
Model | VAA‑4E4A‑KE‑ZE/R |
Communication Protocol | AS-Interface (AS-i) |
Inputs | 4 digital inputs |
Outputs | 4 digital outputs |
Input Type | PNP |
Output Type | Electronic, PNP, overload protected |
Rated Voltage | 26.5 V to 31.6 V DC (via AS-i) |
Max Output Current | 2 A total (0.5 A per channel typical) |
Connection (AS-i) | Flat cable via piercing contacts |
Field Device Connection | M12 connectors |
Protection Class | IP67 |
Operating Temp | –25 °C to +70 °C |
Mounting | Screw-mounted or DIN rail |
Applications
-
Machine-level distributed I/O
-
Packaging machinery
-
Conveyors and material handling systems
-
Harsh environment I/O expansion
-
Modular automation systems
Why Choose the VAA‑4E4A‑KE‑ZE/R
-
Simplifies wiring with flat cable and M12 connectors
-
Fully encapsulated for harsh industrial conditions
-
Compact, space-saving design
-
Status LEDs support fast diagnostics
-
Reliable decentralized control in AS‑i networks
Order Now
The Pepperl+Fuchs VAA‑4E4A‑KE‑ZE/R AS‑Interface module is available and ships worldwide.
