Siemens 6ES7522-1BL10-0AA0 | S7-1500 Digital Output Module – 8x 24VDC, 2A, Source, 35mm Width
Overview
The Siemens 6ES7522-1BL10-0AA0 is a S7-1500 digital output module designed for 24V DC sourcing applications in automation systems. It provides 8 output channels, each capable of delivering 2A, and fits in a compact 35 mm housing. This high-performance module ensures reliable control of actuators and digital devices in industrial environments.
Key Features
-
Output Channels: 8 digital outputs
-
Output Voltage: 24V DC (source)
-
Output Current: 2A per channel
-
Module Width: 35 mm
-
Isolation: Yes, between channels and backplane
-
Diagnostics: Short circuit and wire break detection
-
LED Indicators: Channel status and fault
-
Mounting: DIN rail (via S7-1500 rack)
-
Connection Type: Front connector (screw/spring terminals)
Technical Specifications
-
Part Number: 6ES7522-1BL10-0AA0
-
Series: S7-1500
-
Module Type: DO 8x24VDC/2A ST
-
Supply Voltage Range: 19.2–28.8V DC
-
Power Dissipation: Approx. 6W
-
Ambient Temperature: 0°C to +60°C
-
Dimensions (W x H x D): 35 x 147 x 129 mm
-
Weight: Approx. 240 g
-
Certifications: CE, UL, CSA
Applications
-
Actuator control
-
Industrial automation systems
-
Process and machine control
-
Digital load switching
-
PLC expansion for S7-1500 systems
Why Choose the 6ES7522-1BL10-0AA0?
-
High Output Power: 2A per channel for demanding loads
-
Compact Design: Saves space in control cabinets
-
Integrated Diagnostics: Improves system reliability
-
Easy Integration: Seamless with S7-1500 PLCs
-
Reliable Performance: Backed by Siemens engineering
Order Now
Order the Siemens 6ES7522-1BL10-0AA0 for reliable digital output in your S7-1500 automation system.
