Siemens 3RW3018-1BB14 | SIRIUS 3RW30 Soft Starter – 7.5 kW, 18 A

Overview

The Siemens 3RW3018-1BB14 is a soft starter from the SIRIUS 3RW30 series, built to control the startup and stop behavior of three-phase asynchronous motors. It supports motors rated up to 7.5 kW at 400V, with a current rating of 18 A, and operates with a 24V AC/DC control voltage. Designed for compact control panel installations, it helps reduce mechanical stress and electrical inrush during motor startup.


Key Features

  • Rated Motor Power: 7.5 kW @ 400V

  • Rated Operational Current: 18 A

  • Control Voltage: 24V AC/DC

  • Built-in Bypass Contacts: Reduces heat and energy loss after startup

  • Adjustable Start/Stop Parameters: Ramp-up and ramp-down time

  • Size: S0 – space-saving for standard panels

  • LED Indication: Operational and fault status

  • Mounting: DIN rail or screw-mount

  • Ambient Temperature Range: -25°C to +60°C

  • IP Rating: IP20 (with optional cover)


Technical Specifications

  • Catalog Number: 3RW3018-1BB14

  • Product Line: SIRIUS 3RW30

  • Input Voltage: 200–480V AC, 3-phase

  • Output Frequency: 50/60 Hz

  • Overload Capability: 4x rated current for 10 seconds

  • Protection Class: IP20

  • Certifications: CE, UL, CSA, RoHS

  • Dimensions (W x H x D): Approx. 55 mm x 145 mm x 130 mm

  • Country of Origin: Germany


Applications

  • Pump and Fan Control

  • Material Handling Systems

  • HVAC Motors

  • Machine Tools

  • Conveyors and Mixers


Why Choose the 3RW3018-1BB14?

  • Smooth Start/Stop: Reduces wear on motors and mechanical systems

  • Energy Efficient: Built-in bypass saves power during operation

  • Compact and Reliable: Fits easily into S0-size panels

  • Flexible Control Voltage: Compatible with 24V AC or DC systems

  • Backed by Siemens Quality: Proven durability and support


Order Now

In stock and ready for worldwide delivery.

New & Genuine Products – Factory Sealed At PLCpartssolution, all our products are 100% new, genuine, and come in original factory-sealed packaging. We guarantee authentic components that meet the highest industry standards for performance and reliability.
1-Year Warranty Included All new products sold by PLCpartssolution come with a 1-year warranty. We stand behind the quality and reliability of our parts, ensuring coverage against manufacturing defects under normal operating conditions.
