Allen-Bradley 1794-IM8 FLEX I/O 8-point 120V AC input module, DIN rail mount, sinking input type

Allen-Bradley 1794-IM8

SKU: 1794-IM8
Your Price:
$438.00
Add to wishlist
Checkout Secure
Order in the next to get it by

10+ Available in Stock

  • Image of Free Shipping on All Orders

    Free Shipping on All Orders
  • Image of 1 Year Warranty

    We will beat any price

    1 Year Warranty
  • Image of Experts Aavaiable 7/24/365

    Free shipping

    Experts Aavaiable 7/24/365
  • Image of 30 days money-back

    30 days money-back

Allen-Bradley 1794-IM8

Overview

The Allen-Bradley 1794-IM8 is a 120V AC input module in the FLEX I/O family, featuring 8 sinking input channels for monitoring AC field signals in distributed control systems. It is designed for mounting on DIN rails as part of a modular FLEX I/O system, offering space-saving and flexible input/output configuration in industrial automation applications.

Key Features

  • I/O Type: Digital input module

  • Input Channels: 8 sinking inputs

  • Voltage Rating: 120V AC nominal

  • Input Type: AC sinking (accepts sourcing field devices)

  • Mounting Style: DIN rail

  • Series: 1794 FLEX I/O

  • Field Power: External supply required

  • Wiring Interface: Compatible with 1794-TB or 1794-TBN terminal bases

  • Status Indicators: Channel-level LED indicators

Technical Specifications

  • Catalog Number: 1794-IM8

  • Voltage Range: 74–132V AC

  • Nominal Voltage: 120V AC

  • Input Current (typical): ~10 mA @ 120V AC

  • On/Off Delay: <20 ms typical

  • Backplane Current Load: Approx. 30 mA

  • Isolation Voltage: 120V AC continuous

  • Operating Temp: 0°C to 55°C

  • Certifications: UL, CSA, CE

  • Compatible Platforms: FLEX I/O adapters for ControlLogix, CompactLogix, and PLC-5 systems

Applications

  • Monitoring of switches, sensors, and pushbuttons in 120V AC systems

  • Distributed control architectures using FLEX I/O

  • Industrial machinery with modular I/O requirements

  • Panel-building and OEM equipment

  • Retrofitting legacy AC control circuits

Why Choose the 1794-IM8

  • Flexible Installation: Part of space-saving FLEX I/O modular system

  • High Voltage Input: Accepts standard 120V AC signals

  • Reliable Performance: Proven Allen-Bradley durability

  • Clear Diagnostics: Input status LEDs for quick troubleshooting

  • Scalable Design: Easily expands I/O in a compact footprint

Order Now

The Allen-Bradley 1794-IM8 FLEX I/O input module is available and ships worldwide.



New & Genuine Products – Factory Sealed At PLCpartssolution, all our products are 100% new, genuine, and come in original factory-sealed packaging. We guarantee authentic components that meet the highest industry standards for performance and reliability.
1-Year Warranty Included All new products sold by PLCpartssolution come with a 1-year warranty. We stand behind the quality and reliability of our parts, ensuring coverage against manufacturing defects under normal operating conditions.
Disclaimer: PLCpartssolution is an independent supplier of surplus and refurbished industrial automation products. We are not an authorized distributor, reseller, or representative of the brands listed on this website. All trademarks, brand names, and logos are the property of their respective owners. PLCpartssolution is not affiliated with, endorsed by, or approved by ABB, Fanuc, B&R, Rockwell Automation, Schneider Electric, Siemens, or any other manufacturers mentioned.
