Allen-Bradley 440R-EM4R2
Overview
The Allen-Bradley 440R-EM4R2 is a Guardmaster safety relay expansion module designed to increase the number of safety outputs in a system. Operating at 24V DC, it provides four normally open (N.O.) safety outputs and is intended for use with base safety relays that support single-wire safety (SWS) connections. Its compact design and IP40 enclosure rating make it suitable for various industrial applications.
Key Features
-
Power Supply: 24V DC
-
Safety Outputs: 4 N.O. contacts
-
Auxiliary Outputs: 1 N.C. solid-state
-
Input Type: Single-wire safety (SWS) input
-
Enclosure Rating: IP40
-
Mounting: DIN rail
-
Terminal Type: Screw terminals
-
Certifications: CE, cULus, TUV
-
Safety Standards: SIL 3 (IEC 61508), PLe (ISO 13849-1)
Technical Specifications
-
Catalog Number: 440R-EM4R2
-
Power Consumption: 3.5 W
-
Maximum Output Current: 2 A @ 24V DC
-
Aggregate Output Current: 6 A
-
Surge Output Current: 700 mA (max), 5 ms duration
-
Operating Voltage Range: 20.4V to 26.4V DC
-
Operating Temperature: -5°C to +55°C
-
Storage Temperature: -40°C to +85°C
-
Relative Humidity: 5% to 95% non-condensing
-
Mechanical Life: 10,000,000 operations
-
Dimensions (H x W x D): 119.14 mm x 22.5 mm x 113.6 mm
-
Weight: Approximately 0.227 kg
Applications
-
Expansion of safety outputs in existing safety relay systems
-
Integration with base units supporting SWS connections
-
Industrial machinery requiring additional safety contacts
-
Systems adhering to high safety integrity levels (SIL 3, PLe)
Why Choose the 440R-EM4R2?
-
Scalable Safety Solutions: Easily expand safety output capacity without overhauling existing systems.
-
High Safety Standards: Complies with SIL 3 and PLe, ensuring robust safety performance.
-
Compact Design: Saves panel space with its slim profile and DIN rail mounting.
-
Reliable Operation: Offers high mechanical life and robust performance in industrial environments.
Order Now
The Allen-Bradley 440R-EM4R2 Guardmaster Safety Relay Expansion Module is available and ready to enhance your safety system.
