Allen-Bradley 700-HLT1L1 timer relay, SPDT, 0.1–10 sec, 120V AC coil, on-delay, blade terminal

Allen-Bradley 700-HLT1L1

SKU: 700-HLT1L1
Your Price:
$126.00
Add to wishlist
Checkout Secure
Order in the next to get it by

10+ Available in Stock

  • Image of Free Shipping on All Orders

    Free Shipping on All Orders
  • Image of 1 Year Warranty

    We will beat any price

    1 Year Warranty
  • Image of Experts Aavaiable 7/24/365

    Free shipping

    Experts Aavaiable 7/24/365
  • Image of 30 days money-back

    30 days money-back

Allen-Bradley 700-HLT1L1

Overview

The Allen-Bradley 700-HLT1L1 is a time delay relay designed for precise on-delay timing control in industrial automation systems. Featuring a single-pole double-throw (SPDT) contact, an adjustable 0.1 to 10 second time range, and a 120V AC coil, this unit is ideal for applications that require delayed switching. The blade terminal connections ensure quick and secure installation into relay sockets.

Key Features

  • Function: On-delay timer

  • Contact Type: SPDT (1 Form C)

  • Timing Range: 0.1 to 10 seconds (adjustable)

  • Coil Voltage: 120V AC

  • Terminals: Blade (for plug-in socket)

  • Timing Accuracy: ±10%

  • Repeat Accuracy: ±1%

  • Mounting Type: Socket-based installation

Technical Specifications

  • Catalog Number: 700-HLT1L1

  • Series: 700-HL

  • Contact Rating: 10 A @ 250V AC / 30V DC (resistive load)

  • Operating Temp: -20°C to +60°C

  • Reset Time: ≤ 100 ms

  • Dimensions: Compact plug-in form factor

  • Certifications: UL, cUL, CE, CSA

  • Timing Mechanism: Solid-state

Applications

  • Delay start functions for motors and fans

  • Control of solenoids, valves, and lighting

  • Sequential process automation

  • Panel-mounted timing logic circuits

Why Choose the 700-HLT1L1

  • Precise and adjustable delay control

  • Reliable solid-state timing

  • SPDT output supports versatile control

  • Easily integrates into control panels with socket mounting

Order Now

The Allen-Bradley 700-HLT1L1 timer relay is available and ships worldwide.

New & Genuine Products – Factory Sealed At PLCpartssolution, all our products are 100% new, genuine, and come in original factory-sealed packaging. We guarantee authentic components that meet the highest industry standards for performance and reliability.
1-Year Warranty Included All new products sold by PLCpartssolution come with a 1-year warranty. We stand behind the quality and reliability of our parts, ensuring coverage against manufacturing defects under normal operating conditions.
Disclaimer: PLCpartssolution is an independent supplier of surplus and refurbished industrial automation products. We are not an authorized distributor, reseller, or representative of the brands listed on this website. All trademarks, brand names, and logos are the property of their respective owners. PLCpartssolution is not affiliated with, endorsed by, or approved by ABB, Fanuc, B&R, Rockwell Automation, Schneider Electric, Siemens, or any other manufacturers mentioned.
