Allen-Bradley 700-HLT1U1 time delay relay, on-delay, 0.05–10 sec, SPDT, 120V AC coil, 8-pin octal plug-in

Allen-Bradley 700-HLT1U1

SKU: 700-HLT1U1
Your Price:
$108.00
Add to wishlist
Checkout Secure
Order in the next to get it by

10+ Available in Stock

  • Image of Free Shipping on All Orders

    Free Shipping on All Orders
  • Image of 1 Year Warranty

    We will beat any price

    1 Year Warranty
  • Image of Experts Aavaiable 7/24/365

    Free shipping

    Experts Aavaiable 7/24/365
  • Image of 30 days money-back

    30 days money-back

Allen-Bradley 700-HLT1U1

Overview

The Allen-Bradley 700-HLT1U1 is a compact plug-in on-delay time delay relay designed for general-purpose timing applications. With a time range of 0.05 to 10 seconds and a single-pole double-throw (SPDT) contact configuration, it provides precise and reliable time-delay functionality in control panels. This relay is equipped with a 120V AC coil and mounts to a standard 8-pin octal base for easy installation and replacement.

Key Features

  • Function: On-delay time delay

  • Time Range: 0.05–10 seconds (adjustable via dial)

  • Contact Type: SPDT (Single-Pole Double-Throw)

  • Coil Voltage: 120V AC, 50/60 Hz

  • Mounting: Plug-in (8-pin octal base)

  • LED indicator for power/status

  • High timing accuracy and repeatability

  • Manual time setting dial on front face

  • UL, CSA, CE approved

Technical Specifications

  • Catalog Number: 700-HLT1U1

  • Timing Function: On-delay

  • Time Delay Range: 0.05 to 10 seconds

  • Coil Voltage: 120V AC

  • Contact Rating:

    • 10A @ 240V AC / 30V DC resistive

  • Contact Configuration: 1 SPDT

  • Mounting: 8-pin octal socket

  • Operating Temperature: -20°C to +60°C (-4°F to 140°F)

  • Power Consumption: Approx. 2 VA

  • Dimensions (H x W x D): Approx. 3.0 x 1.0 x 1.5 in (76 x 25 x 38 mm)

  • Weight: Approx. 0.2 lbs (0.09 kg)

Applications

  • Industrial automation panels

  • Motor and pump delay start circuits

  • Conveyor sequencing

  • Fan and lighting control delay

  • HVAC control systems

Why Choose the 700-HLT1U1

  • Reliable and precise time-delay performance

  • Simple installation with plug-in design

  • Adjustable timing range to suit various applications

  • Trusted Allen-Bradley quality and durability

Order Now

The Allen-Bradley 700-HLT1U1 time delay relay is in stock and ready to ship.

New & Genuine Products – Factory Sealed At PLCpartssolution, all our products are 100% new, genuine, and come in original factory-sealed packaging. We guarantee authentic components that meet the highest industry standards for performance and reliability.
1-Year Warranty Included All new products sold by PLCpartssolution come with a 1-year warranty. We stand behind the quality and reliability of our parts, ensuring coverage against manufacturing defects under normal operating conditions.
Disclaimer: PLCpartssolution is an independent supplier of surplus and refurbished industrial automation products. We are not an authorized distributor, reseller, or representative of the brands listed on this website. All trademarks, brand names, and logos are the property of their respective owners. PLCpartssolution is not affiliated with, endorsed by, or approved by ABB, Fanuc, B&R, Rockwell Automation, Schneider Electric, Siemens, or any other manufacturers mentioned.
