Siemens 3SK1121-2AB40 | Basic SIRIUS Safety Relay – 24V DC, 3NO + 1NC for Emergency Stop & Safety Gate Monitoring
Overview
The Siemens 3SK1121-2AB40 is a SIRIUS safety relay designed for emergency stop, safety door monitoring, and light curtain integration in standard industrial applications. Operating at 24V DC, it offers 3 normally open (NO) safety outputs and 1 normally closed (NC) signaling output, with support for both 1-channel and 2-channel input configurations.
Key Features
-
Input Channels: 1- or 2-channel safety inputs
-
Output Contacts:
-
3 × NO (Safety Contacts)
-
1 × NC (Monitoring/Signal Contact)
-
-
Control Voltage: 24V DC
-
Response Time: < 30 ms
-
Mounting: 35 mm DIN rail (EN 60715)
-
Status Indicators: LED indicators for input and output status
-
Width: 22.5 mm – space-saving design
-
Protection Rating: IP20 (housing), IP40 (front)
Technical Specifications
-
Part Number: 3SK1121-2AB40
-
Series: SIRIUS 3SK1
-
Rated Voltage: 24V DC
-
Rated Current (per output): Up to 6A @ 250V AC
-
Utilization Category: AC-15, DC-13
-
Operating Temperature: –25°C to +55°C
-
Dimensions (HxWxD): Approx. 100 × 22.5 × 120 mm
-
Certifications: CE, UL, CSA, TUV, SIL 3, PL e, Cat. 4, RoHS
Applications
-
Emergency stop pushbuttons
-
Safety door switches and interlocks
-
Safety light curtains
-
Two-hand control systems
-
General machine safety logic
Why Choose the 3SK1121-2AB40?
-
Flexible Configuration: Supports 1- and 2-channel applications
-
Compact Design: Saves space in control panels
-
Compliant with Global Standards: SIL 3 / PL e / Cat. 4 certified
-
Quick Installation: Screw terminals and clear LED diagnostics
-
Reliable Siemens Safety: Proven in industrial automation
Order Now
The Siemens 3SK1121-2AB40 safety relay is in stock and available for global shipping.
