Siemens 6ES7422-1BL00-0AA0 | S7-400 DO Module – 32 x 24V DC Sink Outputs

Overview

The Siemens 6ES7422-1BL00-0AA0 is a 32-channel digital output module for the SIMATIC S7-400 PLC system. Designed for 24V DC sink-type outputs, it delivers reliable and fast switching of actuators and indicators in large-scale industrial automation applications. Each output channel is individually isolated, enhancing safety and signal integrity.


Key Features

  • Number of Outputs: 32 digital channels

  • Output Type: 24V DC, sink (positive common)

  • Output Current: 0.5 A per channel

  • Isolation: Channel-to-channel and group isolation

  • Status LEDs: Per channel indication for diagnostics

  • Connection Type: Front connector (not included)

  • Protection Functions: Short-circuit and overload protection

  • Hot-Swappable: Replaceable without powering down the rack

  • Mounting: S7-400 rack slot


Technical Specifications

  • Catalog Number: 6ES7422-1BL00-0AA0

  • System Compatibility: SIMATIC S7-400

  • Output Delay: Typically <1 ms

  • Power Supply: Via backplane bus

  • Output Voltage Range: 20.4 to 28.8V DC

  • Ambient Temperature: 0°C to +60°C

  • Protection Rating: IP20

  • Dimensions (W x H x D): Approx. 50 mm x 290 mm x 210 mm

  • Weight: Approx. 700 g

  • Certifications: CE, UL, CSA, RoHS

  • Country of Origin: Germany


Applications

  • Large-Scale Machine Control

  • Factory and Process Automation

  • Material Handling Systems

  • Power Distribution Panels

  • Water Treatment and Utilities


Why Choose the 6ES7422-1BL00-0AA0?

  • High Channel Density: 32 outputs in one module

  • Isolated Channels: Enhanced safety and signal separation

  • Fast Switching Performance: <1 ms for real-time response

  • Ideal for Industrial Environments: Built to S7-400 reliability standards

  • Comprehensive Diagnostics: LED status for easy fault detection


Order Now

Available for immediate worldwide shipment.

New & Genuine Products – Factory Sealed At PLCpartssolution, all our products are 100% new, genuine, and come in original factory-sealed packaging. We guarantee authentic components that meet the highest industry standards for performance and reliability.
1-Year Warranty Included All new products sold by PLCpartssolution come with a 1-year warranty. We stand behind the quality and reliability of our parts, ensuring coverage against manufacturing defects under normal operating conditions.
Disclaimer: PLCpartssolution is an independent supplier of surplus and refurbished industrial automation products. We are not an authorized distributor, reseller, or representative of the brands listed on this website. All trademarks, brand names, and logos are the property of their respective owners. PLCpartssolution is not affiliated with, endorsed by, or approved by ABB, Fanuc, B&R, Rockwell Automation, Schneider Electric, Siemens, or any other manufacturers mentioned.
