Siemens 6SE6420-2UD21-5AA1 | MICROMASTER 420 Frequency Inverter – 1.5 kW, 3AC 400V
Overview
The Siemens 6SE6420-2UD21-5AA1 is a MICROMASTER 420 variable frequency drive (VFD) designed for controlling the speed and torque of three-phase motors in a wide range of applications. Rated at 1.5 kW (2 HP) and operating on 3AC 400V input, this compact inverter features sensorless vector control, making it ideal for conveyor systems, fans, and pumps.
Key Features
-
Power Rating: 1.5 kW (2 HP)
-
Input Voltage: 3AC 380–480V ±10%, 50/60 Hz
-
Output Frequency: 0–650 Hz
-
Control Method: V/f and sensorless vector control
-
Integrated I/O:
-
3 digital inputs
-
2 analog inputs
-
1 relay output
-
-
Interface: RS485 (USS protocol)
-
Protection Rating: IP20
-
Mounting: Panel or DIN rail
Technical Specifications
-
Part Number: 6SE6420-2UD21-5AA1
-
Series: MICROMASTER 420
-
Output Current: Approx. 4.2 A
-
Braking: Integrated DC braking (external resistor optional)
-
Display: Optional BOP/AOP operator panel
-
Dimensions (HxWxD): Approx. 206 × 90 × 152 mm
-
Operating Temp: –10°C to +50°C (derating above)
-
Certifications: CE, UL, cULus, RoHS, EN 61800-3
Applications
-
Conveyor belts
-
Fans and pumps
-
Packaging and textile machinery
-
Basic automation systems
-
Energy-efficient motor control
Why Choose the 6SE6420-2UD21-5AA1?
-
Compact Design: Saves cabinet space
-
Reliable Motor Control: Sensorless vector performance
-
Integrated I/O: No need for extra modules
-
Easy Setup: Quick commissioning via RS485 or optional panels
-
Siemens Quality: Durable and proven in industrial environments
Order Now
The Siemens 6SE6420-2UD21-5AA1 MICROMASTER 420 inverter is in stock and available for global shipping.
