Siemens 6SL3244-0BB13-1FA0 | SINAMICS G120 PM240-2 Power Module – 7.5 kW, 400V, Frame C

Overview

The Siemens 6SL3244-0BB13-1FA0 is a PM240-2 power module from the SINAMICS G120 modular drive system, designed for 7.5 kW motors operating on 3-phase 400V supply. This version includes an integrated brake chopper and is built with IP20 protection in a Frame Size C housing. It connects with compatible control units (CU230, CU240, CU250) for flexible motion control in industrial environments.

Key Features

  • Power Rating: 7.5 kW (10 HP)

  • Input Voltage: 3AC 380–480V ±10%, 50/60 Hz

  • Output Current (rated): Approx. 17 A

  • Integrated Brake Chopper: Yes

  • Frame Size: C

  • Protection Class: IP20

  • Cooling Method: Internal air cooling

  • Mounting: Control cabinet (panel mounting)

  • Communication Ready: Supports modular CU integration for PROFINET, PROFIBUS, etc.

  • Standards Compliance: IEC/EN 61800

Technical Specifications

  • Part Number: 6SL3244-0BB13-1FA0

  • Series: SINAMICS G120 PM240-2

  • Operating Temperature: –10°C to +50°C (derating above)

  • Dimensions (HxWxD): Approx. 330 × 140 × 180 mm

  • Weight: Approx. 4.5 kg

  • Certifications: CE, UL, cULus, EAC, RoHS

  • Installation Altitude: Up to 1000 m without derating

Applications

  • Pumps, fans, and compressors

  • Conveyor systems

  • Packaging and textile machinery

  • HVAC systems

  • General-purpose industrial automation

Why Choose the 6SL3244-0BB13-1FA0?

  • Reliable Motor Control: Ideal for mid-range 3-phase applications

  • Integrated Braking: Handles rapid deceleration loads

  • Modular Design: Pair with various control units for tailored functionality

  • Space-Saving Build: Compact Frame C for control cabinets

  • Trusted Siemens Engineering: Proven G120 series quality

Order Now

The Siemens 6SL3244-0BB13-1FA0 power module is in stock and ready for worldwide shipping.

New & Genuine Products – Factory Sealed At PLCpartssolution, all our products are 100% new, genuine, and come in original factory-sealed packaging. We guarantee authentic components that meet the highest industry standards for performance and reliability.
1-Year Warranty Included All new products sold by PLCpartssolution come with a 1-year warranty. We stand behind the quality and reliability of our parts, ensuring coverage against manufacturing defects under normal operating conditions.
Disclaimer: PLCpartssolution is an independent supplier of surplus and refurbished industrial automation products. We are not an authorized distributor, reseller, or representative of the brands listed on this website. All trademarks, brand names, and logos are the property of their respective owners. PLCpartssolution is not affiliated with, endorsed by, or approved by ABB, Fanuc, B&R, Rockwell Automation, Schneider Electric, Siemens, or any other manufacturers mentioned.

Description

Siemens 6SL3244-0BB13-1FA0 | SINAMICS G120 PM240-2 Power Module – 7.5 kW, 400V, Frame C

Overview

The Siemens 6SL3244-0BB13-1FA0 is a PM240-2 power module from the SINAMICS G120 modular drive system, designed for 7.5 kW motors operating on 3-phase 400V supply. This version includes an integrated brake chopper and is built with IP20 protection in a Frame Size C housing. It connects with compatible control units (CU230, CU240, CU250) for flexible motion control in industrial environments.

Key Features

  • Power Rating: 7.5 kW (10 HP)

  • Input Voltage: 3AC 380–480V ±10%, 50/60 Hz

  • Output Current (rated): Approx. 17 A

  • Integrated Brake Chopper: Yes

  • Frame Size: C

  • Protection Class: IP20

  • Cooling Method: Internal air cooling

  • Mounting: Control cabinet (panel mounting)

  • Communication Ready: Supports modular CU integration for PROFINET, PROFIBUS, etc.

  • Standards Compliance: IEC/EN 61800

Technical Specifications

  • Part Number: 6SL3244-0BB13-1FA0

  • Series: SINAMICS G120 PM240-2

  • Operating Temperature: –10°C to +50°C (derating above)

  • Dimensions (HxWxD): Approx. 330 × 140 × 180 mm

  • Weight: Approx. 4.5 kg

  • Certifications: CE, UL, cULus, EAC, RoHS

  • Installation Altitude: Up to 1000 m without derating

Applications

  • Pumps, fans, and compressors

  • Conveyor systems

  • Packaging and textile machinery

  • HVAC systems

  • General-purpose industrial automation

Why Choose the 6SL3244-0BB13-1FA0?

  • Reliable Motor Control: Ideal for mid-range 3-phase applications

  • Integrated Braking: Handles rapid deceleration loads

  • Modular Design: Pair with various control units for tailored functionality

  • Space-Saving Build: Compact Frame C for control cabinets

  • Trusted Siemens Engineering: Proven G120 series quality

Order Now

The Siemens 6SL3244-0BB13-1FA0 power module is in stock and ready for worldwide shipping.
