Pepperl+Fuchs NBB20‑L2M‑A2‑V1 | Inductive Proximity Sensor | 20 mm Sensing | M30 Housing | Cable Version
Overview
The NBB20‑L2M‑A2‑V1 is a high-standard inductive proximity sensor by Pepperl+Fuchs, featuring a 20 mm sensing distance in a robust M30 metal housing. The integrated pre-wired cable simplifies installation for industrial automation systems requiring reliable, non-contact metal detection.
Key Features
-
Sensing Distance: 20 mm (flush mount)
-
Output: PNP, Normally Open (NO)
-
Wiring: Pre-attached 3‑wire cable
-
Connection: Axial cable lead (standard length)
-
Housing: Nickel-plated brass, M30 thread
-
Ingress Protection: IP67 – dust and water resistant
-
Indicator LED: Visual output monitoring
-
Switching Speed: High-frequency switching up to ~200 Hz
Technical Specifications
Specification | Details |
---|---|
Model | NBB20‑L2M‑A2‑V1 |
Supply Voltage | 10–30 V DC |
Sensing Range (Sn) | 20 mm (flush) |
Switching Frequency | ≤ 200 Hz |
Output Current | Max 200 mA |
Voltage Drop | ≤ 2 V |
Operating Temp. | –25 °C to +70 °C |
Protection Class | IP67 |
Housing Length | ~75 mm (M30) |
Mounting Style | Flush |
Connection Type | Pre-wired cable |
Applications
-
Metal part detection in conveyors and packaging lines
-
Position sensing in manufacturing and assembly stations
-
Robotics and automated machinery systems
-
OEM equipment installation with pre-wired convenience
-
Industrial environments exposed to water, dust, and vibration
Why Choose NBB20‑L2M‑A2‑V1
-
Extended 20 mm detection range in flush mount design
-
Pre-wired cable eliminates connector prep and reduces downtime
-
Durable M30 housing ensures longevity in harsh conditions
-
Easy diagnostics via integrated LED status indicator
-
Smooth PLC integration with PNP NO output
Order Now
The Pepperl+Fuchs NBB20‑L2M‑A2‑V1 inductive proximity sensor is available and ships worldwide.
