Siemens 6ED1055-1MB00-0BA2 | LOGO! Expansion Module – 8 Digital Inputs, 24V DC, IP20, Screw Terminals
Overview
The Siemens 6ED1055-1MB00-0BA2 is a LOGO! 8 expansion module that adds 8 digital inputs to your existing LOGO! logic controller setup. Operating at 24V DC, this compact module is ideal for enhancing I/O capacity in small automation systems such as building control, HVAC, or simple industrial machinery.
Key Features
-
Digital Inputs: 8 (24V DC)
-
Connection Type: Screw terminals for secure wiring
-
Input Type: Sinking/sourcing configurable
-
Power Supply: 24V DC
-
Mounting: DIN rail compatible
-
Module Compatibility: LOGO! 8 logic controllers
-
Status LEDs: Individual channel indication for diagnostics
-
Protection Class: IP20 (suitable for cabinet installation)
Technical Specifications
-
Part Number: 6ED1055-1MB00-0BA2
-
Series: LOGO! 8
-
Input Voltage Range: 20.4 to 28.8 V DC
-
Input Current (typical): 3 mA per input
-
Isolation: Inputs isolated from logic
-
Dimensions (W x H x D): Approx. 72 x 90 x 55 mm
-
Weight: Approx. 160 g
-
Operating Temperature: 0°C to +55°C
-
Certifications: CE, UL, cULus, RoHS
Applications
-
Building automation (lighting, security)
-
Water pump and irrigation systems
-
HVAC system control
-
Educational and training PLC environments
-
Simple industrial automation tasks
Why Choose the 6ED1055-1MB00-0BA2?
-
Expandable I/O: Adds 8 digital inputs to your LOGO! 8 controller
-
Compact Design: Ideal for tight cabinet spaces
-
Easy Wiring: Screw terminals for safe, fast installation
-
Cost-Effective: Affordable I/O expansion for small systems
-
Seamless Integration: Fully compatible with LOGO! 8 CPUs
Order Now
The Siemens 6ED1055-1MB00-0BA2 LOGO! expansion module is in stock and ready for global shipping.
